Warenkorb ist leer| Einheit: | |
| Code: | 260-013 |
| Modell: | GB-LBS + GB-LBASE |
| Produktgarantie (Monaten): | 60 |
| Hersteller: | Deye |
Description
The Deye High Voltage Battery Cluster Control Box (GB-HV-BMS-BOX) and Mounting Base (GB-LBASE) are core system structural and management components for Deye's High Voltage modular battery systems (GB-LM4.0 / GB-L series). The Control Box houses the master Battery Management System (BMS), high-voltage DC protection breakers, surge protection, and power distribution interfaces for the battery stack. The GB-LBASE provides a floor-mounted foundation that supports stacked lithium battery modules and facilitates safe cableless interconnects. Backed by a 10-year manufacturer warranty, the system manages safety, cell balancing, and communication between the energy storage cluster and Deye high-voltage hybrid inverters.
Key Features & Benefits
Master High-Voltage BMS: Monitors cell voltages, system state-of-charge (SoC), temperatures, and controls high-voltage DC contactors and breakers across the battery cluster.
Integrated Safety & Protection: Built-in DC circuit breaker, fuses, thermal control, and surge protection for safe high-voltage DC operation up to 750V+.
10-Year Extended Warranty: Backed by a standard 10-year factory warranty for industrial-grade durability and long-term energy storage reliability.
Heavy-Duty GB-LBASE Floor Mount: Engineered base structure designed to support high static weight loads of stacked $\text{LiFePO}_4$ modules while maintaining leveling and seismic stability.
Cableless Interconnect Support: Facilitates internal quick-plug power and communication interfaces between stacked battery units, reducing installation footprint and field wiring errors.
Technical Specifications
| Parameter | Specification |
| Product Component Types | Master HV Cluster Control Box (BMS) + Floor Mounting Base |
| Compatible Battery Modules | Deye GB-LM4.0 / GB-L Series High-Voltage $\text{LiFePO}_4$ Modules |
| Operating Voltage Range | 150 V – 750 V DC (High Voltage Architecture) |
| Max. Charge / Discharge Current | 40 A – 50 A (System cluster dependent) |
| Communication Protocols | CAN 2.0 / RS485 to Inverter; Internal Bus to Slave BMS |
| System Warranty | 10 Years |
| Operating Temperature Range | -20°C to +55°C (Discharge) / 0°C to +55°C (Charge) |
| Enclosure Protection Rating | IP65 (Indoor and Outdoor Floor Installation) |
| Control Box Dimensions (W x D x H) | ~540 × 385 × 220 mm |
| Control Box Weight | ~15.5 kg |
| Mounting Base (GB-LBASE) Dimensions | ~540 × 385 × 110 mm |
| Mounting Base Weight | ~8.0 kg |
| P |
Weight
24 kg |
